CEILING BLANKET

Mammoth 100% polyester insulation blanket to reduce heat transfer through ceilings.



Description

Mammoth ceiling blankets are designed to be installed in new or existing roof cavities.

An effective and easy form of thermal insulation, Mammoth® Modern Insulation ceiling blankets have a range of R-values of up to R4.0, or R8.0 when double layered. Mammoth blankets are long lasting, won't sag or settle over time, are non-irritant and highly effective. Mammoth products contain recycled polyester fibres. Mammoth ceiling blanket insulation uses up to 7,400 recycled PET plastic bottles per 100sqm*.

For new ceilings without a roof space there is the option of our Mammoth Skillion Ceiling Sections and for skillion and truss roofs we have Mammoth Ceiling Battens.

Can be double layered to meet the new Building Code.

Mammoth ceiling blankets are manufactured in roll form so that they can be installed as both a single or double layer system. For any system - single or double layered - the joist depth must be greater than the insulation thickness.

Mammoth ceiling blankets are designed in widths to fit snugly between joists or trusses in a single layer option or alternatively with a second layer run perpendicular to the first, covering the top of the joists or truss bottom chord reducing thermal bridging in these areas.

Description

Mammoth ceiling blankets are designed to be installed in new or existing roof cavities.

An effective and easy form of thermal insulation, Mammoth® Modern Insulation ceiling blankets have a range of R-values of up to R4.0, or R8.0 when double layered. Mammoth blankets are long lasting, won't sag or settle over time, are non-irritant and highly effective. Mammoth products contain recycled polyester fibres. Mammoth ceiling blanket insulation uses up to 7,400 recycled PET plastic bottles per 100sqm*.

For new ceilings without a roof space there is the option of our Mammoth Skillion Ceiling Sections and for skillion and truss roofs we have Mammoth Ceiling Battens.

Can be double layered to meet the new Building Code.

Mammoth ceiling blankets are manufactured in roll form so that they can be installed as both a single or double layer system. For any system - single or double layered - the joist depth must be greater than the insulation thickness.

Mammoth ceiling blankets are designed in widths to fit snugly between joists or trusses in a single layer option or alternatively with a second layer run perpendicular to the first, covering the top of the joists or truss bottom chord reducing thermal bridging in these areas.

GALLERY/VIDEOS



SPECIFICATIONS




PRODUCT RANGE PACK SIZES
Density (kg/m3) R-Value Nominal thickness (mm) Dimensions (mm) Pieces per pack Area per pack (m2)
Ceiling Blanket 7.83 R 1.8 115 870 x 11495 2 20
7.57 R 2.9 185 870 x 8620 2 15
8.00 R 3.2 200 870 x 8620 2 15
8.00 R 3.3 210 870 x 8620 2 15
8.00 R 3.6 225 870 x 7470 2 13
8.33 R 4.0 240 870 x 5750 2 10
Double Layer - R 2.9 x 2 7.57 R 5.8 370 870 x 8620 2 15*
Double Layer - R 3.2 x 2 8.00 R 6.4 400 870 x 8620 2 15*
Double Layer - R 3.3 x 2 8.00 R 6.6 420 870 x 8620 2 15*
Double Layer - R 3.6 x 2 8.00 R 7.2 450 870 x 7470 2 13*
Double Layer - R 4.0 x 2 8.33 R 8.0 480 870 x 5750 2 10*


For any system - single or double layered - the joist depth must be greater than the insulation thickness.
* For Double Layering - Double the quantity of product is required. For instance, a 100m2 area requires 200m2 of product to achieve a double layer.


  • Soft, roll-form 100% polyester insulation blanket for ceilings. Can be double layered for higher R-value.
  • Mammoth ceiling blanket insulation uses up to 7,400 recycled PET plastic bottles per 100sqm*. * Calculations are based on 500ml PET Bottles (16.2g).
  • Unaffected by moisture, Mammoth will continue to perform once dried out. Mammoth is moisture, mould and mildew resistant.
  • Lightweight and easy to handle - can easily be torn to length or cut with shears. Available in varying widths and lengths to suit most applications.
  • Heat bonded - no glues or binders that can break down so it won't sag or settle over time.
  • Red List Free - no formaldehyde or pesticides added.
  • Safe, non-itch, odourless and non-toxic - no precautions are required for handling the product.
  • All Mammoth ceiling blankets are BRANZ 797 Appraised.
  • All Mammoth ceiling blankets have Eco Choice Aotearoa (prev. Environmental Choice) certification.
  • Mammoth products are made in a zero waste production process and are fully recyclable.
  • Mammoth ceiling insulation products have an ODP of zero.
  • Long lasting, Mammoth insulation is performance warranted for 50 years (T&Cs apply).
  • Manufactured by InZone Industries Ltd, a NZ Toitū carbonreduce certified insulation manufacturing organisation.

Technical Attributes Standard Test Result
New Zealand Building Code
Durability Clause B2.3.1 (a) (b)
Clause B2.3.2 		Ref: BRANZ Appraisal No 7971
Internal Moisture Clause E3.3.1 Ref: BRANZ Appraisal No 7971
Hazardous Building Materials Clause F2.3.1 Ref: BRANZ Appraisal No 7971
Energy Efficiency Clause H1.3.1(a)
Clause H1.3.2 E		 Ref: BRANZ Appraisal No 7971
Product Safety
Non Toxic OSH Health and Safety Guidelines2 Polyester products are ‘non-toxic’
Non Irritant OSH Health and Safety Guidelines2 Polyester products are ‘non-irritant’
Respiratory Safe n/a Polyester fibres are non-respirable
Fire Test AS/NZS60695.2.11 Passed - Glow wire flammability test
AS/NZS60695.11.5 Passed - Test flames (Needle-flame test)
ISO9705 Group1S
Can safely cover IC-rated downlights. If luminare rating is unknown, minimum clearance of 100mm to any insulation is required.
VOC Emission Safe 3 Total VOC ≤ 0.5mg/m3 < 0.005mg/m3 - level below detection4
Formaldehyde ≤ 0.06mg/m3 < 0.009mg/m3 - level below detection
Glue Free Free from all glues
Other
Non Corrosive AS/NZS4859.1 Materials composed entirely of polyester are regarded as non-corrosive and are exempt from testing. Alkalinity of pH 7.8
Vermin Resistant Not a food source for vermin (and not treated)

1 Meet or contribute to these provisions when designed, used, installed and maintained in accordance with BRANZ Appraisal 797.
2 Occupational Safety and Health Service. Health and Safety Guidelines for the Selection and Safe Handling of Synthetic Mineral Fibres, Dept of Labour, 1994.
3 Mammoth has been tested under ASTM D5116. Based on test results for a product with similar nominal weight.
4 All individual VOCs were less than their threshold limit values. Carcinogens and reproductive toxins were not identified as part of the VOCs.


  • Soft, roll-form 100% polyester insulation blanket for ceilings. Can be double layered for higher R-value.
  • Mammoth ceiling blanket insulation uses up to 7,400 recycled PET plastic bottles per 100sqm*. * Calculations are based on 500ml PET Bottles (16.2g).
  • Unaffected by moisture, Mammoth will continue to perform once dried out. Mammoth is moisture, mould and mildew resistant.
  • Lightweight and easy to handle - can easily be torn to length or cut with shears. Available in varying widths and lengths to suit most applications.
  • Heat bonded - no glues or binders that can break down so it won't sag or settle over time.
  • Red List Free - no formaldehyde or pesticides added.
  • Safe, non-itch, odourless and non-toxic - no precautions are required for handling the product.
  • All Mammoth ceiling blankets are BRANZ 797 Appraised.
  • All Mammoth ceiling blankets have Eco Choice Aotearoa (prev. Environmental Choice) certification.
  • Mammoth products are made in a zero waste production process and are fully recyclable.
  • Mammoth ceiling insulation products have an ODP of zero.
  • Long lasting, Mammoth insulation is performance warranted for 50 years (T&Cs apply).
  • Manufactured by InZone Industries Ltd, a NZ Toitū carbonreduce certified insulation manufacturing organisation.

PRODUCT RANGE PACK SIZES
Density (kg/m3) R-Value Nominal thickness (mm) Dimensions (mm) Pieces per pack Area per pack (m2)
Ceiling Blanket 7.83 R 1.8 115 870 x 11495 2 20
7.57 R 2.9 185 870 x 8620 2 15
8.00 R 3.2 200 870 x 8620 2 15
8.00 R 3.3 210 870 x 8620 2 15
8.00 R 3.6 225 870 x 7470 2 13
8.33 R 4.0 240 870 x 5750 2 10
Double Layer - R 2.9 x 2 7.57 R 5.8 370 870 x 8620 2 15*
Double Layer - R 3.2 x 2 8.00 R 6.4 400 870 x 8620 2 15*
Double Layer - R 3.3 x 2 8.00 R 6.6 420 870 x 8620 2 15*
Double Layer - R 3.6 x 2 8.00 R 7.2 450 870 x 7470 2 13*
Double Layer - R 4.0 x 2 8.33 R 8.0 480 870 x 5750 2 10*


For any system - single or double layered - the joist depth must be greater than the insulation thickness.
* For Double Layering - Double the quantity of product is required. For instance, a 100m2 area requires 200m2 of product to achieve a double layer.


Technical Attributes Standard Test Result
New Zealand Building Code
Durability Clause B2.3.1 (a) (b)
Clause B2.3.2 		Ref: BRANZ Appraisal No 7971
Internal Moisture Clause E3.3.1 Ref: BRANZ Appraisal No 7971
Hazardous Building Materials Clause F2.3.1 Ref: BRANZ Appraisal No 7971
Energy Efficiency Clause H1.3.1(a)
Clause H1.3.2 E		 Ref: BRANZ Appraisal No 7971
Product Safety
Non Toxic OSH Health and Safety Guidelines2 Polyester products are ‘non-toxic’
Non Irritant OSH Health and Safety Guidelines2 Polyester products are ‘non-irritant’
Respiratory Safe n/a Polyester fibres are non-respirable
Fire Test AS/NZS60695.2.11 Passed - Glow wire flammability test
AS/NZS60695.11.5 Passed - Test flames (Needle-flame test)
ISO9705 Group1S
Can safely cover IC-rated downlights. If luminare rating is unknown, minimum clearance of 100mm to any insulation is required.
VOC Emission Safe 3 Total VOC ≤ 0.5mg/m3 < 0.005mg/m3 - level below detection4
Formaldehyde ≤ 0.06mg/m3 < 0.009mg/m3 - level below detection
Glue Free Free from all glues
Other
Non Corrosive AS/NZS4859.1 Materials composed entirely of polyester are regarded as non-corrosive and are exempt from testing. Alkalinity of pH 7.8
Vermin Resistant Not a food source for vermin (and not treated)

1 Meet or contribute to these provisions when designed, used, installed and maintained in accordance with BRANZ Appraisal 797.
2 Occupational Safety and Health Service. Health and Safety Guidelines for the Selection and Safe Handling of Synthetic Mineral Fibres, Dept of Labour, 1994.
3 Mammoth has been tested under ASTM D5116. Based on test results for a product with similar nominal weight.
4 All individual VOCs were less than their threshold limit values. Carcinogens and reproductive toxins were not identified as part of the VOCs.

Installation
Mammoth Ceiling Insulation must be installed according to the manufacturer’s guidelines and in accordance with NZS 4246 (Energy Efficiency - Installing Insulation in Residential Buildings). Installation Instructions for Mammoth Ceiling Insulation can be found here. Contact us on 0800 MAMMOTH for more details.

50 Year Warranty
Mammoth Insulation has a 50 year warranty. Our product warranty covers that - so long as the insulation is installed correctly and remains adequately protected Mammoth insulation will perform for 50 years. The warranty applies only to 100% polyester insulation products manufactured by InZone Industries Ltd. Read the full warranty for terms and conditions.

BRANZ Appraised
Mammoth Ceiling Insulation Blanket has been tested by, and is covered by BRANZ Appraisal 797.


DOWNLOAD DATASHEET
Mammoth Ceiling Blanket Installation Guidelines


Q&A/FREQUENTLY ASKED QUESTIONS



R-Value is a measure of thermal efficiency - is measures the thermal resistance of the material. The higher the R-Value the better.

Minimum R-Values are specified for ceilings in the building code.

The New Zealand Building Code specifies minimum R-Values for ceiling insulation in different geographic regions of New Zealand. Read more here.

Yes you can. Mammoth ceiling insulation is very easy to work with as it is non-irritant and is designed to roll out over joists.

We encourage you to read the Installation Guidelines for Ceiling Blanket carefully since all insulation must be carefully placed around fire hazards like downlights and chimneys.

You can purchase Mammoth ceiling insulation from most building merchants although, due to its bulk, they may not all have it in stock - we suggest you ring ahead for pricing and they can order in your specific requirements.

Ceiling insulation sections are designed to be placed between joists which can allow for heat to be lost in the gaps - this is thermal bridging. In contrast ceiling insulation blanket rolls out over the joists to prevent thermal bridging.

All Mammoth insulation products are heat bonded and contain no glues or other materials that may break down over time.

And if you ever need to remove Mammoth insulation, our products are 100% recyclable.
