Acoustic Panel Absorber

A high-performance acoustic panel to control noise reverberation.



Description

Mammoth® Panel Absorber is designed to be used as an interior surface lining in commercial or residential spaces to help reduce noise reverberation.

Mammoth® Panel Absorber acoustic insulation is a 100% polyester semi rigid board in white, white with black face, black or grey. With a Group 1S fire rating under the ISO 9705 Fire test, it is suitable for use in exit ways and a variety of occupied spaces and HVAC systems.

Mammoth Panel Absorber is available in various densities and thicknesses, ranging from 35-25mm, 35-50mm, 35-75mm, 20-100mm and 40-100mm and are 2400mm x 1200mm panel sizes. Custom cuts are available for larger projects with MOQ.

Mammoth Panel Absorber is manufactured using two different processes, airlay and card. While the functions and specifications of Mammoth Panel Absorber produced in both ways remain the same, the appearance is different, which is most apparent on the grey panels. Airlay manufacturing produces a distinctly mottled grey finish, while the card is a more uniform grey with some tonal variations.

Panel Absorber is suitable for use in most exposed applications, but is primarily designed for acoustic performance rather than a high visual finish as it may show some creasing, finish and colour variations.

Please contact your local Mammoth representative for more information and samples.

Description

Mammoth® Panel Absorber is designed to be used as an interior surface lining in commercial or residential spaces to help reduce noise reverberation.

Mammoth® Panel Absorber acoustic insulation is a 100% polyester semi rigid board in white, white with black face, black or grey. With a Group 1S fire rating under the ISO 9705 Fire test, it is suitable for use in exit ways and a variety of occupied spaces and HVAC systems.

Mammoth Panel Absorber is available in various densities and thicknesses, ranging from 35-25mm, 35-50mm, 35-75mm, 20-100mm and 40-100mm and are 2400mm x 1200mm panel sizes. Custom cuts are available for larger projects with MOQ.

Mammoth Panel Absorber is manufactured using two different processes, airlay and card. While the functions and specifications of Mammoth Panel Absorber produced in both ways remain the same, the appearance is different, which is most apparent on the grey panels. Airlay manufacturing produces a distinctly mottled grey finish, while the card is a more uniform grey with some tonal variations.

Panel Absorber is suitable for use in most exposed applications, but is primarily designed for acoustic performance rather than a high visual finish as it may show some creasing, finish and colour variations.

Please contact your local Mammoth representative for more information and samples.

GALLERY/VIDEOS



SPECIFICATIONS




PRODUCT RANGE PACK SIZES
Acoustic Panel Absorber Density/ Thickness (mm) NRC MOQ (m2) R-Value Airlay / Card Dimensions (mm) Pieces per pack Area per pack (m2)
White 35/ 25 0.70 500 NA Card 2400 x 1200 12 34.56
35/ 50 0.90 No MOQ NA Card 2400 x1200 6 17.28
35/ 75 0.95 500 NA Aitlay 2400 x 1200 4 11.52
20/ 100 1.05 500 NA Airlay 2400 x 1200 3 8.64
40/ 100 1.05 500 NA Airlay 2400 x 1200 3 8.64
White with Black Face 35/ 25 0.70 No MOQ R 0.7 Card 2400 x 1200 12 34.56
35/ 50 0.90 No MOQ R 1.4 Card 2400 x 1200 6 17.28
35/ 75 0.95 250 R 2.0 Airlay 2400 x 1200 4 11.52
20/ 100 1.05 250 NA Airlay 2400 x 1200 3 8.64
40/ 100 1.05 250 NA Airlay 2400 x 1200 3 8.64
Black with Black Face 35/ 25 0.70 250 NA Airlay 2400 x 1200 12 34.56
35/ 50 0.90 No MOQ NA Airlay 2400 x 1200 6 17.28
35/ 75 0.95 250 NA Airlay 2400 x 1200 4 11.52
20/ 100 1.05 500 NA Airlay 2400 x 1200 3 8.64
40/ 100 1.05 500 NA Airlay 2400 x 1200 3 8.64
Grey 35/ 25 0.70 250 NA Card 2400 x 1200 12 34.56
35/ 50 0.90 250 NA Card 2400 x 1200 6 17.28
35/ 75 0.95 250 NA Airlay 2400 x 1200 4 11.52
20/ 100 1.05 250 NA Airlay 2400 x 1200 3 8.64

  • Mammoth Panel Absorber (previously NOVAhush) provides acoustic benefits for residential and commercial applications.
  • High acoustic performance - up to NRC 1.05.
  • Safe to use as an Interior surface liner - ISO 9705 Fire Test - Group 1S rating.
  • Mammoth acoustic products reduce sound transmission at all frequencies.
  • Safe, non-irritant, non-itch, odourless and non-toxic - no precautions are required for handling the product.
  • Unaffected by moisture, Mammoth insulation will continue to perform once dried out.
  • Mammoth is moisture, mould and mildew resistant.
  • Heat bonded - no glues or binders that can break down so it won't sag or settle over time.
  • Lightweight and easy to handle - can easily be cut using wide blade craft knives or specialised insulation saws.
  • Available in 4 colours, white, white with black face, black and grey. MOQ’s apply to some colours - please refer to the datasheet.
  • Red List Free - no formaldehyde or pesticides added.
  • NZ Green Building Council approved.
  • Long lasting, Mammoth insulation is performance warranted for 50 years (T&Cs apply).
  • Mammoth insulation products manufactured from 100% polyester have an Ozone Depleting Potential (ODP) of zero.
  • Manufactured by InZone Industries Ltd, a NZ Toitū carbonreduce certified insulation manufacturing organisation.

Technical Attributes Standard Test Result
New Zealand Building Code
Durability Clause B2.3.1 (a) (b)
Clause B2.3.2
Internal Moisture Clause E3.3.1
Hazardous Building Materials Clause F2.3.1
Product Safety
Non Toxic OSH Health and Safety Guidelines1 Polyester products are ‘non-toxic’
Non Irritant OSH Health and Safety Guidelines1 Polyester products are ‘non-irritant’
Respiratory Safe n/a Polyester fibres are non-respirable
Fire Test ISO 9075 Group 1S
AS/NZS60695.2.11 Passed - Glow wire flammability test
AS/NZS60695.11.5 Passed - Test flames (Needle-flame test)
VOC Emission Safe3 Total VOC ≤ 0.5mg/m3 < 0.005mg/m3 - level below detection 2
Formaldehyde ≤ 0.06mg/m3 < 0.009mg/m3 - level below detection
Glue Free Free from all glues or chemical binders
Other
Non Corrosive NZS 4222 Alkalinity of pH 7.8
Vermin Resistant n/a Not a food source for vermin (and not treated)

1 Occupational Safety and Health Service. Health and Safety Guidelines for the Selection and Safe Handling of Synthetic Mineral Fibres, Dept,of Labour, 1994.
2 Mammoth has been tested under ASTM D5116. Based on test results for a product with similar nominal weight.
3 All individual VOCs were less than their threshold limit values. Carcinogens and reproductive toxins were not identified as part of the VOCs.

Mammoth Panel Absorber is compliant with the Building Code of Australia C1.1 (AS ISO 9705) and the New Zealand Building Code C/VM2 (ISO 9705) as a surface lining material for walls and ceilings and also as a HVAC duct liner.

Mammoth panel absorber can be manufactured in other dimensions subject to minimum order quantities. Mammoth panel absorber is designed for acoustic application and not recommended for visual applications as the surface may show creases, wrinkles or slight colour variations due to the manufacturing process.

Thermal resistances are estimates based on test results for products with similar nominal weight.


  • Mammoth Panel Absorber (previously NOVAhush) provides acoustic benefits for residential and commercial applications.
  • High acoustic performance - up to NRC 1.05.
  • Safe to use as an Interior surface liner - ISO 9705 Fire Test - Group 1S rating.
  • Mammoth acoustic products reduce sound transmission at all frequencies.
  • Safe, non-irritant, non-itch, odourless and non-toxic - no precautions are required for handling the product.
  • Unaffected by moisture, Mammoth insulation will continue to perform once dried out.
  • Mammoth is moisture, mould and mildew resistant.
  • Heat bonded - no glues or binders that can break down so it won't sag or settle over time.
  • Lightweight and easy to handle - can easily be cut using wide blade craft knives or specialised insulation saws.
  • Available in 4 colours, white, white with black face, black and grey. MOQ’s apply to some colours - please refer to the datasheet.
  • Red List Free - no formaldehyde or pesticides added.
  • NZ Green Building Council approved.
  • Long lasting, Mammoth insulation is performance warranted for 50 years (T&Cs apply).
  • Mammoth insulation products manufactured from 100% polyester have an Ozone Depleting Potential (ODP) of zero.
  • Manufactured by InZone Industries Ltd, a NZ Toitū carbonreduce certified insulation manufacturing organisation.

PRODUCT RANGE PACK SIZES
Acoustic Panel Absorber Density/ Thickness (mm) NRC MOQ (m2) R-Value Airlay / Card Dimensions (mm) Pieces per pack Area per pack (m2)
White 35/ 25 0.70 500 NA Card 2400 x 1200 12 34.56
35/ 50 0.90 No MOQ NA Card 2400 x1200 6 17.28
35/ 75 0.95 500 NA Aitlay 2400 x 1200 4 11.52
20/ 100 1.05 500 NA Airlay 2400 x 1200 3 8.64
40/ 100 1.05 500 NA Airlay 2400 x 1200 3 8.64
White with Black Face 35/ 25 0.70 No MOQ R 0.7 Card 2400 x 1200 12 34.56
35/ 50 0.90 No MOQ R 1.4 Card 2400 x 1200 6 17.28
35/ 75 0.95 250 R 2.0 Airlay 2400 x 1200 4 11.52
20/ 100 1.05 250 NA Airlay 2400 x 1200 3 8.64
40/ 100 1.05 250 NA Airlay 2400 x 1200 3 8.64
Black with Black Face 35/ 25 0.70 250 NA Airlay 2400 x 1200 12 34.56
35/ 50 0.90 No MOQ NA Airlay 2400 x 1200 6 17.28
35/ 75 0.95 250 NA Airlay 2400 x 1200 4 11.52
20/ 100 1.05 500 NA Airlay 2400 x 1200 3 8.64
40/ 100 1.05 500 NA Airlay 2400 x 1200 3 8.64
Grey 35/ 25 0.70 250 NA Card 2400 x 1200 12 34.56
35/ 50 0.90 250 NA Card 2400 x 1200 6 17.28
35/ 75 0.95 250 NA Airlay 2400 x 1200 4 11.52
20/ 100 1.05 250 NA Airlay 2400 x 1200 3 8.64

Technical Attributes Standard Test Result
New Zealand Building Code
Durability Clause B2.3.1 (a) (b)
Clause B2.3.2
Internal Moisture Clause E3.3.1
Hazardous Building Materials Clause F2.3.1
Product Safety
Non Toxic OSH Health and Safety Guidelines1 Polyester products are ‘non-toxic’
Non Irritant OSH Health and Safety Guidelines1 Polyester products are ‘non-irritant’
Respiratory Safe n/a Polyester fibres are non-respirable
Fire Test ISO 9075 Group 1S
AS/NZS60695.2.11 Passed - Glow wire flammability test
AS/NZS60695.11.5 Passed - Test flames (Needle-flame test)
VOC Emission Safe3 Total VOC ≤ 0.5mg/m3 < 0.005mg/m3 - level below detection 2
Formaldehyde ≤ 0.06mg/m3 < 0.009mg/m3 - level below detection
Glue Free Free from all glues or chemical binders
Other
Non Corrosive NZS 4222 Alkalinity of pH 7.8
Vermin Resistant n/a Not a food source for vermin (and not treated)

1 Occupational Safety and Health Service. Health and Safety Guidelines for the Selection and Safe Handling of Synthetic Mineral Fibres, Dept,of Labour, 1994.
2 Mammoth has been tested under ASTM D5116. Based on test results for a product with similar nominal weight.
3 All individual VOCs were less than their threshold limit values. Carcinogens and reproductive toxins were not identified as part of the VOCs.

Mammoth Panel Absorber is compliant with the Building Code of Australia C1.1 (AS ISO 9705) and the New Zealand Building Code C/VM2 (ISO 9705) as a surface lining material for walls and ceilings and also as a HVAC duct liner.

Mammoth panel absorber can be manufactured in other dimensions subject to minimum order quantities. Mammoth panel absorber is designed for acoustic application and not recommended for visual applications as the surface may show creases, wrinkles or slight colour variations due to the manufacturing process.

Thermal resistances are estimates based on test results for products with similar nominal weight.

Installation

Mammoth Panel Absorber must be installed according to the manufacturer’s guidelines. Installation Instructions for Mammoth Panel Absorber can be found at www.mammoth.co.nz/downloads. Contact us on 0800 MAMMOTH for more details.

50 Year Warranty

Mammoth Insulation has a 50 year warranty. Our product warranty covers that - so long as the insulation is installed correctly and remains adequately protected - Mammoth insulation will perform for 50 years. The warranty applies only to 100% polyester insulation products manufactured by InZone Industries Ltd and not to other composite products manufactured by InZone Industries Ltd. Read the full warranty at www.mammoth.co.nz for terms and conditions.


DOWNLOAD DATASHEET
Mammoth Panel Absorber Installation Guidelines
